Split Face CMU

Jandris Split Face CMU’s are extremely durable, fire and mold resistant, and energy efficient due to high thermal mass. The raw materials used to produce most colors of our Split Face Blocks are local.

Jandris Split Face Blocks are fractured using a splitter exposing natural aggregates and creating a natural “rock-like” surface. They can be used for maintenance-free interior and/or exterior applications.

Variations of Split Face CMU

Single Score Split Face

One horizontal score line across the split face surface.

Seven Groove Eight Rib Split

Deep vertical ribbing for bold texture and shadow.

Three Groove Four Rib Split

Wider ribs for a more pronounced vertical pattern.

One Groove Two Rib Split

Minimal ribbing for a subtle scored look.

Four Rib Split

Evenly spaced vertical ribs on a split face surface.

Standard Split Face

Classic fractured surface with no scoring or ribbing.

View Color Selection

Sizes & Specifications

Split Face Blocks are available in various shapes and sizes, including half units, half high units, bond beams and lintels (where reinforcing is needed), corners (one face and one end split), and custom shapes upon request.

Nominal Size	Actual Size (WxHxL)	Weight
4x8x16	3⅝×7⅝×15⅝	26 lb
6x8x16	5⅝×7⅝×15⅝	33 lb
8x8x16	7⅝×7⅝×15⅝	38 lb
10x8x16	9⅝×7⅝×15⅝	43 lb
12x8x16	11⅝×7⅝×15⅝	53 lb

Available Options

Insulation Inserts

Hi-R & Hi-R-H insulated units for energy code compliance and thermal performance. All architectural finishes are available with factory-installed Korfil insulation inserts, delivering tested R-Values up to R-18.

Learn about Insulated CMU

CarbonX Low Carbon Option

All architectural finishes are available with CarbonX technology, which lowers embodied carbon by reducing cement content and increasing CO₂ sequestration — by up to 50%, depending on the product.

Learn about CarbonX
